Overview
Here’s an overview of its key features:
- Form factor: Supports M-ATX and Mini-ITX motherboards.
- Aesthetics: Tempered glass on both the front and left side panels allows you to showcase your internal components.
- Cooling and lighting: Includes three pre-installed ARGB fans for vibrant lighting and effective cooling.
- Storage support: Features several drive bays for storage expansion, specifically 2 bays for 3.5″ HDDs and 1 bay for a 2.5″ SSD.
- Hardware clearance:
- CPU cooler: Can accommodate coolers up to 160mm in height.
- Graphics card: Supports GPUs with a maximum length of 320mm.
- Power supply: Supports standard ATX PSUs with a maximum length of 160mm, and the PSU is bottom-mounted.
- Radiator support: Supports liquid cooling radiators up to 240mm on the top.
- Connectivity: The top-mounted I/O panel includes one USB 3.0 port, two USB 1.0 ports, and HD audio jacks.
Specifications
Structure Size: 330*272*300mm
Product Size: 330*272*313mm
Material/Front panel: 0.45mm SPCC, Front panel glass
Left/Right side panel: Left side panel tempered glass *4pcs screw, right side panel with metal
Motherboard: MATX
ODD: Not Support
Driver Bays: HDD*1, SSD*1
USB: 1*USB1.0+1*USB3.0+HD Audio
Support VGA card(Max.): 320mm
Support CPU height(Max.): 157mm
Slots: PCI 4pcs
Fans: M01-Black ARGB cooling fans*3pcs (Master Fan*1pcs+Slave Fan*2pcs) (Top *2pcs, Rear*1pcs), mb sync
Dust Filter: Top with dust filter, Bottom no dust filter
Supporting Water Cooling: Not Support
